It has WiFi, Ethernet and USB, a 10 inch color touchscreen and the MINGDA PI platform for remote printing and multi-machine control.

What power supply does it need?

It runs on 220 V with a maximum power of 3200 W.

MINGDA Raptor 450: IDEX printer with a 500 °C nozzle

Description

MINGDA Raptor 450 3D printer

Industrial FDM 3D printer with independent dual extruders (IDEX) and a heated enclosure, for high-temperature materials (PEEK, PC, PA, fiber composites).

MINGDA Raptor 450 3D printer
450 × 450 × 500 mm build volume, independent dual extruders (IDEX).
Nozzle up to 500 °C, 120 °C heated enclosure, speed up to 300 mm/s.

The Raptor 450 is an industrial printer for high-end engineering materials: an enclosure actively heated up to 120 °C and a 500 °C nozzle for PEEK, PC, PA and fiber-reinforced composites. The IDEX system offers Copy, Mirror, support and two-color modes, and high-flow technology allows speeds of up to 300 mm/s. It also has AI defect detection, HEPA filtration, water cooling for the extruder and a closed housing.

Independent dual extruders (IDEX): Copy / Mirror / support / 2-color modes
120 °C heated enclosure: high-temperature materials (PEEK, PC, PA)
Nozzle up to 500 °C + bed up to 130 °C
Speed up to 300 mm/s: high-flow technology
AI defect detection + HEPA filtration
Water cooling for the extruder / heat break
MINGDA PI platform: remote printing, multi-machine control

MINGDA Raptor 450 3D printer

Specification	MINGDA Raptor 450
Technology	FDM
Build volume	450 × 450 × 500 mm
Copy mode	450 (2×225) × 450 × 500 mm
Mirror mode	390 (2×195) × 450 × 500 mm
Extruder	IDEX (independent extruders)
Layer height	0.16 to 0.24 mm
Nozzle diameter	0.4 mm (optional 0.6 / 0.8 mm)
Max nozzle temperature	500 °C
Max bed temperature	130 °C
Enclosure temperature (constant)	120 °C
Filament box drying	50 °C
Max print speed	300 mm/s
Max flow rate	40 mm³/s
Max power	3200 W
Voltage	220 V
Connectivity	WiFi, Ethernet, USB
Screen	Color touchscreen, 10 inch
Firmware	Klipper
AI detection	Yes
Extruder cooling	Water cooling
Air filtration	HEPA filter
Build plate	Thick aluminum + PEI
Leveling	Automatic, fast
Certification	CE
Machine dimensions	877 × 799 × 1262 mm
Compatible materials	PEEK, ABS, ASA, PETG, ABS-CF, PC, PA, PC-CF, PET-CF, PET-GF, etc.

Frequently asked questions

What are the IDEX modes?

The two independent extruders support Copy, Mirror, support and two-color modes. Copy mode gives a 450 (2×225) × 450 × 500 mm area and Mirror mode gives 390 (2×195) × 450 × 500 mm.

Can it print PEEK?

PEEK is on the manufacturer's list of compatible materials. The nozzle reaches 500 °C and the enclosure can be held at 120 °C.

Does it have air filtration?

Yes. It has a HEPA filter and a closed housing.

How is it connected?
